Ashly ne8250
The ne8250PE from Ashly is a professional-quality 8-channel power amplifier with Ethernet capability designed for installed applications. Housed in a robust 2RU enclosure, this highly-efficient amplifier uses standard Euroblock input and output connectors, allowing it to connect to practically any 4 or 8 Ohm system.
The ne8250PE has an Ethernet port, which offers Ethernet control and monitoring of the amplifier functions using the Proteane software. It also has a normal/bridge switch, allowing you to switch the amplifier into Bridge Mode. Other features include a wide complement of protection circuitry, remote level control, and the ability to expand the unit's capability via optional expansion modules.
This PE model offers internal DSP processing, which allows each input channel to be configured with pluggable DSP blocks for dynamic control, gain functions, graphic and/or parametric EQ, time delay, and more. A mixer section with assignable routing gives you the option to drive any or all output from any input channel. The amplifier outputs have the same DSP benefits as the inputs, with the addition of automated crossover setup.
- Professional Quality
- The rugged 2RU enclosure fits in any standard equipment rack
- Multichannel
- The amplifier provides 8 channels of audio I/O
- Ethernet Control
- The built-in Ethernet port gives you the ability to control and monitor amplifier functions over a network using the Proteane software
- Connectivity
- Standard Euroblock input and output connectors provide wide compatibility with 4 and 8 Ohm systems
- Bridge Mode
- The amplifier can be switched between Normal and Bridge modes if desired
- Protection Circuitry
- Built-in protection circuitry guards against damage from overheating and overcurrent
- LED Displays
- Multiple LED displays show the status of signal, power, standby, protect, power switch disable, and comm activity
- Remote Features
- In addition to software control, the amplifier also has connections for remote standby and remote level control
- DSP
- The integrated DSP features, along with the Proteane software, allow you to configure each input for dynamics control, gain functions, graphic and/or parametric EQ, high and low pass filters, time delay, metering, and test signal generator. A mixer section lets you assign routing to deliver any input to any and all outputs. The outputs have the same DSP functions as the inputs, as well as an automated crossover setup. Up to 35 presets and sub presets can be set for storage and retrieval of global parameters
- Optional Expansion
- Multiple expansion modules are available for adding additional functionality, such as DSP, AES/EBU connectivity, mic inputs, or CobraNet networking
-
Technical specs
Power Rating 150W/Channel @ 8 Ohms
250W/Channel @ 4 Ohms
500W @ 8 Ohms Bridge ModeDamping Factor > 250 Input Level 21dB Input Impedance 20 kOhms, Balanced Gain -50 to 12dB Frequency Response 20Hz - 20kHz Signal-to-Noise Ratio > 98dB Total Harmonic Distortion (THD) < 0.5% Input Connections 8 x Euroblock Inputs
1 x Ethernet Port
1 x Remote Standby Contact
1 x Preset Recall Connector
1 x Data Connector
1 x Remote Level Control Connector
1 x AC Power InputOutput Connectors 8 x Euroblock Outputs Controls Front Panel 1 x Power Switch
8 x Channel Attenuator KnobsControls Rear Panel 1 x Normal/Bridge Switch Indicators 1 x Power LED
1 x Standby LED
1 x Protect LED
1 x Power Switch Disable LED
1 x Comm LED
4 x LED Level Meters
4 x LED Temperature Meters
4 x LED Current MetersCooling Front-to-Rear Airflow Dimensions (WxHxD) 19 x 3.5 x 15.5" (483 x 89 x 394mm) Weight 21 lbs (9.5kg)
