The evolution continues, with the Lian Li O11D EVO PC Case. Taking modular to the next level, this mid-tower chassis can be configured to one of two modes – Normal or Reverse. On top of this, there are multiple positions for I/O panel to be placed, and three orientations for your GPU. Choose from horizontal, vertical, or even upright to fully show off your gaming hardware. Thanks to the mesh panels and spacious interior, airflow has been maximized to the extreme and there is ample support for either AiO or custom water cooling. Plus, with its intelligent dual-chamber design, cable management is easy and the interior will stay looking sleek.

LIAN LI O11D EVO PC CASE WHITE AT A GLANCE:

• Modular aluminium mesh and tempered glass PC case designed with de8aur
• Accommodates up to an E-ATX motherboard
• Two configuration modes: Normal and Reverse Mode
• Choose from three GPU positions: standard, vertical (Require additional hardware), or upright (Require additional hardware)
• Extreme airflow and support for custom water-cooling
• Can hold up to nine SSDs with included brackets

Specifications

Brand: Lian Li
Model: O11D EVO White (O11DEW)
Colour: White
Dimensions: 465mm x 285mm x 459mm D x W x H
Materials: 4mm aluminium, 4mm tempered glass, 1mm steel structure
Motherboard Support: E-ATX (width under 280mm), ATX, Micro-ATX, Mini-ITX
PSU Support: 220mm
Fan Support

• Top: 3 x 120mm or 2 x 140mm
• Side: 3 x 120mm or 2 x 140mm
• Bottom: 3 x 120mm or 2 x 140mm
• Rear: 1 x 120mm
• Drive Cage: 1 x 60mm

Radiator Support
  Top

• 1 x 360mm or 1 x 280mm
• Total max thickness: 87.5mm

  Side

• 1 x 360mm or 1 x 280mm
• Inner scenario total max thickness: 83mm (120mm fans on top and bottom) / 63mm (140mm fans on top and bottom)
• Outer scenario total max thickness: 120mm (120mm fans on top and bottom) / 100mm (140mm fans on top and bottom)

  Bottom

• 1 x 360mm
• Total max thickness: 87.5mm

Drive Support

• Bottom: 4 x 2.5” SSD or 2 x 3.5” HDD
• Side: 4 x 2.5” SSD or 2 x 3.5” HDD
• Drive Cage: 3 x 2.5” SSD or 2 x 3.5” HHD and 1 x 2.5” SSD
• Cable Management Bar: 2 x 2.5” SSD
• Only 9 sets of 2.5” SSD mounting pads are provided

GPU Clearance: 422mm
CPU Height Clearance: 167mm
Expansion Slots: 8
I/O Ports

• 2 x USB 3.0
• 1 x USB 3.1 Type-C
• 1 x HD Audio/Mic
• LED colour and mode button
• Reset button
• Power button

Dust Filter: 1 x Bottom
Weight

• Net: 13.22kg
• Gross: 16.1kg
